S14I Rugged Laptop

Overview

The S14I Rugged Laptop is engineered to combine military-grade durability, field-worker functionality, computing performance, and long battery life for non-stop use. It is suitable for use where rain or dust may occur regularly. For workers in today’s challenging and versatile working environments, the S14I rugged laptop is genuinely in a class of its own.

Get a Quote

High Performance Without Sacrifice

The S14I features a significant CPU upgrade with Intel® Tiger Lake 11th generation platform, using Intel’s 10nm processor technology. This device comes with integrated Intel® Iris Xe graphics, and for professionals who use intensive graphic computing, it can be upgraded to an optional standalone NVIDIA GeForce® GTX1050. With the ultra-high-speed data transmission capability of Intel® Wi-Fi 6 AX201 with a maximum speed of 2.4Gbps and Bluetooth® V5.2, all information is instantly synced and fed back to the data control center.

Exceptional Durability & Security

The S14I is built with a robust mechanical design and rigorously tested components. It meets the standards of MIL-STD-810H, withstands up to a 4-foot drop, and boasts an IP53 rating. This challenging yet elegant rugged laptop breaches the boundary between semi-rugged and fully-rugged devices. It now includes Windows Hello encrypted biometrics, a more secure, user-friendly, and faster way of accessing the Window® 10 OS.

Storage Revolution

S14I is equipped with the latest NVMe PCIe SSD technology, providing up to 1TB of storage, while its PCIe offers speeds 4x faster than SATA III. Furthermore, S14I can accommodate two more internal SSD SATA III drives to maximize onboard storage.

View Every Detail

The S14I sports a Full HD 1080p display and proprietary DynaVue® technology. With brightness enhanced up to 1,000 nits and light-filtering technology providing a high contrast ratio (CR) to eliminate reflection, every imagery detail is delivered with the utmost clarity. The 10-point capacitive multi-touch panel has four Touch Modes (Glove, Stylus, Water, Finger), optimizing the device's use for indoor and outdoor applications.

Continuous Operation on the Go

In the field, portability equals productivity. The S14I weighs only 2.3kg and is 33% slimmer than the previous generation. Adding ultra-long battery life of 10 hours and battery swap capability to its mobile form factor, the S14I enables non-stop operation outside of the office.

Best-in-Class Connectivity

The S14I can communicate in every way, and the S14I says it all: It’s compatible with a full range of interfaces, and the media bay offers all the customized expansion you may need. This laptop leads the market with two digital and one analog video output, HDMI + VGA + USB Type-C DP, smart card / CAC reader, optional PCMCIA or express card, and an RFID reader. Optional customization options abound, with up to two RS-232 serial ports, up to two RJ-45 LAN ports, and an optional Fischer connector.

Dedicated Graphics

The optional dedicated NVIDIA® GEFORCE® GTX1050 transforms the S14I into an ultimate solution for graphics rendering, architectural illustrations, and CAD applications. Only a discrete graphics card can give you the performance and reliability you need to fulfill the demanding job.

Value-Driven In-Vehicle Solution

The S14I in-vehicle laptop is the computing solution that public safety professionals on the front lines can rely on – engineered to improve efficiency in the field with paperless documentation, real-time reporting, applications, communications, mapping, and more. The S14I delivers the features today’s professionals need, along with instant access to the department’s network, databases, and the real-time intelligence needed to keep communities safe.

Do you have any question?

Please feel free to reach out to us. We are ready to help you with your requirements.

S14I Rugged Laptop Anatomy

Front

Rear

Right

Left

Rugged specs

MIL-STD-810H Certified

4′ drop 26 faces, drop, shock, vibration, altitude, freeze/thaw, high/low temperature, temperature shock, humidity

Water and Dust Resistant

IP53

Tech specs

Display

14.0” FHD (1920 x 1080)
Optional 1000 nits DynaVue® sunlight readable display without touch screen
Optional 1000 nits DynaVue® sunlight readable display with capacitive multi-touch screen
User selectable touch mode for Finger/Water, Glove, or Stylus programmable function

Operating System

Windows® 10/11 Pro 64-bit

Processors

Intel® Core™ i7-1185G7 vPro™ (11th Gen) 3.0GHz processor with Turbo Boost Technology up to 4.8GHz, 12MB cache
Intel® Core™ i7-1165G7 (11th Gen) 2.8GHz processor with Turbo Boost Technology up to 4.7GHz, 12MB cache
Intel® Core™ i5-1145G7 vPro™ (11th Gen) 2.6GHz processor with Turbo Boost Technology up to 4.4GHz, 8MB cache
Intel® Core™ i5-1135G7 (11th Gen) 2.4GHz processor with Turbo Boost Technology up to 4.2GHz, 8MB cache
Intel® Core™ i3-1115G4 (11th Gen) 3.0GHz processor with Turbo Boost Technology up to 4.1GHz, 6MB cache

Memory

2 slots 8GB up to 64GB (2400-3200MHz DDR4)

Storage

256GB NVME PCIE SSD
Optional 512GB/1TB PCIE SSD
Optional OPAL 2.0 SSD
Optional 2nd/3rd storage (SATA SSD)²

Graphics

i7/i5: Intel® Iris® Xe Graphics
i3: Intel® UHD Graphics
Optional NVIDIA® GEFORCE GTX 1050^1,8

Camera

Optional integrated 2.0 MP web-cam with shutter design
Optional IR camera for Windows Hello²

Audio

Optional integrated microphone³
Intel® High Definition Audio Compliant
Integrated speaker x 2
Keyboard volume and mute controls

Media Bay

Optional DVD super multi
Optional 2nd battery
Optional media bay storage SSD²
Optional ExpressCard 54 x 1 or PCMCIA Type II x 1^1,2
Optional 2nd RJ-45 & 2nd serial port (RS232)^1,2

I/O Ports

USB 3.2 Gen2 (type A) x 2
USB 3.2 Gen2 (type C) x 1 (support DP)
USB 2.0 (type A) x 1
Audio in/out (combo jack) x 1
SD card (SDXC) x 1
10/100/1000 Ethernet (RJ-45) x 1
VGA port (D-sub,15-pin) x 1
HDMI port (type A) x 1
Serial port (RS232/RS422/RS485 : D-sub,9-pin) x 1
SIM card x 1
DC-In jack x 1
Optional smart card reader x 1⁴
Optional docking connector (41-pin Pogo) x 1
Optional RF antenna pass-through for GPS, WWAN, and WLAN

Keyboard & Pointing Device

2 user-definable keys (P1/P2)
RF Signal slide-switch
Standard membrane keyboard with optional LED backlight

Wireless & Communications

Integrated 10/100/1000 Ethernet
Intel® Wi-Fi 6 AX201 (802.11a/b/g/n/ac/ax)
Bluetooth® V5.2
Optional dedicated GPS module (UBLOX-NEO-M8N)
Optional 4G LTE multi-carrier mobile broadband
Optional RF antenna pass-through for GPS, WWAN, and WLAN

Security

Intel® vPro™ Technology (per CPU options)
TPM 2.0
NIST BIOS compliant
Easy removable SSD
Stealth mode
Kensington lock
Optional smart card reader⁴
Optional Windows Hello²
Optional night vision mode⁵
Optional fingerprint scanner
Optional HF-RFID (NFC) reader^2,4

Power

AC adapter : 100-240V, 50Hz-60Hz, 90W
Optional AC adapter (100-240V, 50Hz-60Hz, 120W), with NVIDIA® VGA
Main battery Li-Ion, 10.8V, 4700mAh, 10 hours⁶
Optional 2nd battery Li-Ion 10.8V, 4700mAh, 10 hours⁶
Optional bridge battery : 5 minutes swap time⁷

Dimension & Weight

350 mm (L) x 282 mm (W) x 38 mm (H)⁸
2.3 kg⁸

Warranty

3-year limited warranty standard

Not available in combination with Intel® Core™ i3-1115G4.
Contact us for feature availability.
Integrated microphone is available only with web-cam.
RFID/NFC and Smart card reader are mutually exclusive.
Night vision mode is available only for sunlight readable display.
Tested using the MobileMark 2014 battery life benchmark. Results may vary under different situations including hardware configuration, software, operating conditions, power management settings and other factors.
The system will stay operating (within 300 seconds in standby mode) when user swaps the battery.
Weight varies with options. The dimension with optional discrete VGA is 61mm/2.4″ (H).
