Asrock IndustrialFanless Embedded BOX PCiBOX-250J
iBOX-250J
iBOX-250J
iBOX-250J
iBOX-250J
iBOX-250J
iBOX-250J
iBOX-250J
iBOX-250J
Fanless Embedded BOX PC

iBOX-250J

  • Intel® Elkhart Lake SoC Processors J6412
  • 2 x 260-pin SO-DIMM DDR4 3200 MHz, up to 32GB(16GB per DIMM)
  • 1 x USB 3.2 Gen2, 3 x USB 2.0, 1 x M.2 Key E, 1 x M.2 Key M, 3 x COM, 1 x SATA3
  • 2 x Intel 2.5 Gigabit LAN
  • Supports dual display, 1 x HDMI 2.0b, 1 x VGA
  • 1 x 19V/65W AC-DC power brick adapter
  • 200 x 134.5 x 39mm (7.87″ x 5.3″ x 1.54″), Fanless Barebone
Get a Quote
Compare
Compare 0
Product Compare
Close
Overview
Specifications
Get a Quote

Processor System

CPU
Intel® Elkhart Lake SoC Processors
iBOX-250J (J6412, QC, Max Speed Up to 2.6GHz, 10W)
Chipset
SoC
BIOS
AMI SPI 256 Mbit

Memory

Technology
Dual Channel DDR4 3200 MHz
Capacity
32GB (16GB per DIMM)
Socket
2 x 260-pin SO-DIMM

Graphics

Controller
Intel® Gen 11 Graphics
HDMI
HDMI 2.0b
Max resolution up to 4096 x 2160@60Hz
MultiDisplay
Dual Display

Expansion Slot

M.2
1 x M.2 (Key E, 2230) with PCIe Gen3 x1 and USB 2.0 for Wireless

Audio

Interface
Realtek ALC256 HD, High Definition Audio

Ethernet

Controller/ Speed
LAN1: Intel® I225V with 10/100/1000/2500 Mbps
LAN2: Intel® I225V with 10/100/1000/2500 Mbps
Connector
2 x RJ-45

Front I/O

USB
2 x USB 2.0

Rear I/O

HDMI
1 x HDMI 2.0b
Ethernet
2 x 2.5 Gigabit LAN
USB
1 x USB 3.2 Gen2, 1 x USB 2.0

Storage

M.2
1 x M.2 (Key M, 2242/2260/2280) with PCIe Gen3 x1 for SSD
SATA
1 x SATA3 (6Gb/s)

Watchdog Timer

Output
From Super I/O to drag RESETCON#
Interval
256 Segments, 0, 1, 2, ...255sec

Power Requirements

Input PWR
9~36V DC-In
Power On
AT/ATX Supported
- AT : Directly PWR on as power input ready
- ATX : Press button to PWR on after power input ready

Environment

Operating Temp
-20ºC ~ 50ºC (With extended temp. peripherals)
Storage Temp
-40° C – 85° C
Operating Humidity
10% ~ 90%
Storage Humidity
10% ~ 90%

Mechanical

Construction
Aluminum housing
Mounting
VESA mount/Wall mount/Din-rail
Dimensions (L x W x H)
200 x 134.5 x 39mm (7.87" x 5.3" x 1.54")
Weight
Net Weight:1.3kg

Others

OS Support
Windows 10/11
TPM
TPM 2.0 onboard IC
Certifications
CE, FCC
Packing List 1
1 x 19V/65W Power Adapter
1 x Wall mount kit
The specification is subject to change without notice in advance. The brand and product names are trademarks of their respective companies. Any configuration other than original product specification is not guaranteed.
